@spectrum-ts/convex

A Convex component for Photon iMessage.

Convex can't run Photon's for await (… of app.messages) loop — that needs a long-lived process. And the usual webhook escape hatch doesn't fit either: app.webhook() dispatches its handler after the HTTP response, but a Convex isolate is frozen the moment the response is returned.

This component inverts that. A delivery is verified and written to a table before the 200 goes back, so an acknowledged message is already durable. Everything after that runs on Convex's scheduler.

It also ships the production pipeline from Photon's architecture guide — burst debouncing, in-flight cancellation, carry-forward, and paced sends — rather than leaving you to rebuild it.

Install

Copy codenpm i @spectrum-ts/convex

Copy code// convex/convex.config.ts
import { defineApp } from "convex/server";
import spectrum from "@spectrum-ts/convex/convex.config";

const app = defineApp();
app.use(spectrum);
export default app;

Set these in the Convex dashboard:

Use

Copy code// convex/spectrum.ts
import { Spectrum } from "@spectrum-ts/convex";
import { components, internal } from "./_generated/api";

export const spectrum = new Spectrum(components.spectrum, {
  onBatch: internal.agent.respond,
  sender: internal.sender.deliver,
  debounceMs: 5000,
  pacingMs: 800,
});

Copy code// convex/http.ts — POST https://<deployment>.convex.site/spectrum/webhook
import { httpRouter } from "convex/server";
import { spectrum } from "./spectrum";

const http = httpRouter();
spectrum.registerRoutes(http);
export default http;

Copy code// convex/agent.ts — one invocation per settled burst
export const respond = internalAction({
  args: { spaceId: v.string(), chainId: v.string(), messages: v.array(v.any()), carried: v.array(v.any()) },
  handler: async (ctx, args) => {
    const reply = await generate(args.messages, args.carried);

    // The scheduler can't interrupt a running action, so re-check after
    // anything slow.
    if (await spectrum.isCancelled(ctx, args)) return null;

    await spectrum.send(ctx, { spaceId: args.spaceId, chainId: args.chainId, content: { type: "text", text: reply } });
    await spectrum.completeChain(ctx, args);
    return null;
  },
});

See example/ for a complete app, including the sender.

How the pipeline behaves

webhook ──▶ verify + enqueue (durable) ──▶ 200
                     │
                     ├─ dedupe on message id (deliveries are at-least-once)
                     └─ start a turn
                                │
                                ▶ your onBatch handler
                                        │
                                        ▶ outbox ─▶ sender ─▶ iMessage

Choosing a turn policy

The component does not impose a conversation model. Pick one with mode:

Copy codenew Spectrum(components.spectrum, {
  onBatch: internal.agent.respond,
  sender: internal.sender.deliver,
  mode: "collapse",   // default is "immediate"
  debounceMs: 0,      // optional extra settling window, collapse mode only
});

debounceMs is a latency cost on every reply, so it defaults to 0 — in collapse mode, cancellation already absorbs most bursts on its own, because a follow-up usually arrives while the previous reply is still in flight.

Guarantees in both modes

• At-least-once deliveries are deduped on the provider message id.
• Read receipts and typing indicators never start a turn. Otherwise a bot replies to the read receipt for its own last message and echoes forever.
• Sends are deduped at the outbox. Each row carries a clientGuid derived from (chainId, seq), so the same logical send is never queued twice. Caveat: the guid is not forwarded to the provider. Photon's send path does not accept a caller-supplied clientMessageId, and the SDK's autoIdempotency mints a fresh key per call — so a retry after a lost acknowledgement can still post twice. Closing that needs an SDK change to thread the key through.
• Messages are never dropped. One rule governs the pipeline: a message is spent only when a reply actually reaches the user — not when it is drained, and not when the handler returns. A handler that has finished has only queued its reply; a follow-up moments later can still cancel it. Until a send is confirmed, every message stays recoverable. Verified live across two back-to-back supersessions.

Sending

Sends go through the outbox to a gRPC transport running in a Node action your app owns. gRPC is the transport for both directions — the SDK's HTTP client has no subscribeEvents / EventsResource, so it cannot serve inbound.

Two pieces of setup are required, and sends fail without them:

1. Depend on the provider and the gRPC peers. @spectrum-ts/imessage is an optional peer of this package, so it is not installed for you:

Copy codenpm i @spectrum-ts/imessage @photon-ai/advanced-imessage nice-grpc nice-grpc-common @grpc/grpc-js

2. Mark them external, and force-reference the peers. createGrpcClient requires its peers resolvable at runtime, not merely bundled:

Copy code// convex.json
{
  "node": {
    "externalPackages": [
      "@photon-ai/advanced-imessage",
      "nice-grpc",
      "nice-grpc-common",
      "@grpc/grpc-js"
    ]
  }
}

Copy code// convex/_workaround.ts — nothing imports this; it exists so the packages ship
"use node";
export * as _grpcJs from "@grpc/grpc-js";
export * as _niceGrpc from "nice-grpc";
export * as _niceGrpcCommon from "nice-grpc-common";

That second file is not optional. Convex installs an externalPackages entry only if the bundled code imports it, and these three are optional peers of @photon-ai/advanced-imessage loaded dynamically from inside that package — so nothing in the bundle references them and they are silently never installed. createGrpcClient then fails its import.meta.resolve check with a misleading "install the peer dependencies" error even though they are in your package.json. The re-export gives the bundler the static reference it needs.

Copy code// convex/sender.ts
"use node";
import { createCloudSender } from "@spectrum-ts/convex/sender";

const sender = createCloudSender(); // one Spectrum() instance per container

The sender drives the ordinary Spectrum() runtime. It is built to be long-lived, which looks wrong for request-scoped execution, but measured it costs ~35ms more to construct than the low-level alternative, tears down in ~1ms, and leaves no active handles — and caching one instance per container removes even that on warm invocations.

Content limitation

ContentInput is string | ContentBuilder: the runtime is designed for in-process composition, where you call text("hi") and hand the builder to send(). A durable outbox has to serialize content to JSON and replay it later, and there is no public way to send a resolved Content back.

So the sender rebuilds what round-trips cleanly — text and markdown — and throws a clear error for anything else rather than silently sending the wrong thing. Attachments, polls and other rich arms would need either a JSON→builder mapper here or an SDK change accepting resolved content.

reply, react and markRead address an existing message, which the public API models as a Message rather than an id, so each costs an extra space.getMessage() round trip (~570ms measured).

Note: node.externalPackages is not honoured by the anonymous local backend (CONVEX_AGENT_MODE=anonymous) — the peers are never installed there regardless of this setup. Use a cloud dev deployment to test sends.

Verified behaviour

Tested against a real Convex deployment (convex dev, local backend) with HMAC-signed webhook deliveries:

The final send returned [spectrum-imessage] Target not allowed for this project for a reserved fictional number — a server-side policy response, which means the whole chain (token mint, TLS, gRPC, auth, request validation) worked.

Docs

docs/integration.mdx.vel is the docs.photon.codes page for this component, staged here rather than in spectrum-ts/docs — that directory is rendered from main, so putting it there publishes it. It ships once this package is on npm and this repo is public; the file header has the steps.

Testing against the component

Apps that install the component register it with convex-test explicitly — its schema and function modules are not part of the app's own glob:

Copy code// convex/setup.test.ts
import { convexTest } from "convex-test";
import spectrum from "@spectrum-ts/convex/test";
import schema from "./schema";

const modules = import.meta.glob("./**/*.ts");

export function initConvexTest() {
  const t = convexTest(schema, modules);
  spectrum.register(t);
  return t;
}

register(t, name?) defaults to "spectrum" — pass the name you installed under if you changed it in convex.config.ts.

Development

This is a single npm package: the root package.json owns both the component and the example app in example/, and root convex.json points functions at example/convex. There is no separate install inside example/.

Copy codenpm install
npm run dev       # codegen + build in watch, alongside `convex dev`

npm run dev runs three things the component needs in order — component codegen, the package build, then convex dev --typecheck-components against the example app. To do a one-off instead:

Copy codenpm run build:codegen   # convex codegen + tsc
npm test
npm run typecheck       # package and example/convex
npm run check           # biome

src/component/_generated/ is committed. It holds component.ts, the ComponentApi type the client re-exports, so regenerate and commit it whenever a component validator changes — npm run build:codegen does both.

Publishing is documented in PUBLISHING.md.

Local development against an SDK checkout. tsconfig.json maps @spectrum-ts/* types to a sibling spectrum-ts checkout's built declarations, so TypeScript uses those rather than checking the SDK's source under this project's lib settings. It is inert without that checkout — TypeScript falls back to normal node resolution when a mapping doesn't resolve — so a plain npm install works unchanged.

License

MIT © Photon
