boxd for Convex

Run boxd machines from your Convex backend. Each machine is a full Linux microVM with its own disk, memory and HTTPS URL. boxd cold-boots a machine in under 10 ms and forks one like a git branch in under 200 ms, and a machine sleeps and wakes with its memory intact. Through this component, create and fork return in under a second, because they also wait until the new machine accepts a command.

The component keeps a reactive row for every machine and every command it runs, so your UI subscribes to machine state and command output with a plain Convex query.

• Create, fork, pause, resume, hibernate, wake, stop, start and destroy machines.
• Run commands and read and write files.
• Put a port on the public internet: https://<machine>.boxd.sh.
• Scope every machine to a user or tenant of your app.
• Get stable error codes to branch on (NOT_FOUND, CONFLICT, ...).

Install

Copy codenpm install @boxd-sh/convex

Create an API key with the boxd CLI and set it on your deployment:

Copy codeboxd auth keys create convex
npx convex env set BOXD_API_KEY bxd_...

A key is fenced to one boxd org. Machines are created in, and billed to, that org.

In a brand-new Convex project, run npx convex dev once first so there is a deployment to set the key on. Its first push fails until the key is set, since the component requires it.

Install the component in convex/convex.config.ts, and bind the key into it:

Copy codeimport { defineApp } from "convex/server";
import { v } from "convex/values";
import boxd from "@boxd-sh/convex/convex.config.js";

const app = defineApp({
  env: { BOXD_API_KEY: v.string() },
});

app.use(boxd, { env: { BOXD_API_KEY: app.env.BOXD_API_KEY } });

export default app;

The key goes into the component's own environment, so it never travels as a function argument.

Use it

Copy code// convex/machines.ts
import { Boxd } from "@boxd-sh/convex";
import { v } from "convex/values";
import { components } from "./_generated/api";
import {
  action,
  query,
  type ActionCtx,
  type QueryCtx,
} from "./_generated/server";

const boxd = new Boxd(components.boxd);

// The component can't see your users, so derive the owner from your auth.
// Never take it from a client argument.
async function ownerId(ctx: QueryCtx | ActionCtx) {
  const identity = await ctx.auth.getUserIdentity();
  if (!identity) throw new Error("Unauthenticated");
  return identity.subject;
}

export const createMachine = action({
  args: {},
  handler: async (ctx) => {
    return await boxd.create(ctx, {
      ownerId: await ownerId(ctx),
      vcpu: 1,
      autoSuspendSeconds: 300,
    });
  },
});

export const run = action({
  args: { machineId: v.string(), command: v.string() },
  handler: async (ctx, { machineId, command }) => {
    return await boxd.exec(ctx, {
      ownerId: await ownerId(ctx),
      machineId,
      command,
    });
  },
});

// Reactive: re-runs whenever one of this user's machine rows changes.
export const myMachines = query({
  args: {},
  handler: async (ctx) => boxd.list(ctx, { ownerId: await ownerId(ctx) }),
});

// Reactive: every command's status and output, newest first.
export const history = query({
  args: { machineId: v.string() },
  handler: async (ctx, { machineId }) =>
    boxd.listExecutions(ctx, { machineId, ownerId: await ownerId(ctx) }),
});

example/convex/example.ts wraps every method this way.

API

Every method takes the Convex ctx first. Reads run in queries. Everything that calls boxd runs in actions. Every call that addresses a machine takes the ownerId it was created with: leave it out and a machine created with an owner is NOT_FOUND (see Owners).

create takes name, image, env, vcpu or memory (size classes 1, 2 or 4 vCPU with 4, 8 or 16 GiB), autoSuspendSeconds, autoDestroySeconds and isolated. The component never stores env.

Owners

Pass ownerId on every call. A machine created with an ownerId is reachable only with that same ownerId, and one created without one only without one. For any other owner, reads return null or [], and actions fail with NOT_FOUND, the same as for a machine that doesn't exist. A fork gets its source's owner.

Keeping rows current

Every row updates the moment a call through the component changes it, and queries over them re-run on their own. boxd can also change a machine without a call, for example auto-suspend after autoSuspendSeconds or auto-destroy after autoDestroySeconds. Call refresh to pick that up, for instance on a timer while a machine is on screen.

Sleeping machines

A paused or hibernated machine wakes by itself when it gets a command or an HTTPS request, so exec works without a resume first. Every transition is idempotent: resume on a running machine succeeds.

Errors

Errors are ConvexErrors with data: { code, message }. Branch on the code with isBoxdError:

Copy codeimport { isBoxdError } from "@boxd-sh/convex";

try {
  await boxd.refresh(ctx, { machineId, ownerId });
} catch (error) {
  if (isBoxdError(error, "NOT_FOUND")) return null;
  throw error;
}

A failed lifecycle call also stores its message in the machine's lastError. The next successful call clears it.

When create or fork makes a machine that then fails to become ready, the error's data.machineId names it. The machine exists, and bills, until you destroy it, so act on that id instead of creating another machine.

Limits

• 10 minute actions. Convex stops an action after 10 minutes, so exec kills its command after timeoutMs: default 9 minutes, at most 9.5. For longer work, start it in the background (nohup ... &) and check on it with later commands.
• Output. exec returns up to 2 million characters per stream. The execution row keeps the first 64,000.
• Files. readFile, readFileBytes and writeFile move at most 8 MiB. Move bigger files with exec, for example with curl.
• New named routes. expose with a name returns at once, but the new URL answers HTTPS only after boxd issues its certificate, typically 15 to 20 seconds later. The default URL answers at once.

How it works

The component calls boxd through the @boxd-sh/sdk web entry, which runs in Convex's default runtime. It exchanges the API key for a session token once, keeps the token in its own table, and reuses it until it nears expiry. boxd rate-limits that exchange per source IP, and Convex deployments share their egress IPs, so each action must not exchange the key again. If boxd revokes the token early, the component exchanges the key again and retries the call once.

Testing your app

Register the component with convex-test:

Copy codeimport { convexTest } from "convex-test";
import boxdTest from "@boxd-sh/convex/test";
import schema from "./schema";

const modules = import.meta.glob("./**/*.ts");

const t = convexTest(schema, modules);
boxdTest.register(t);

To keep tests off the network, mock @boxd-sh/sdk/web with vi.mock. The component's own tests do this: see src/component/setup.test.ts.

Developing this component

Copy codenpm install
npm run build:codegen   # codegen and build dist/
npm run check           # build, typecheck, lint, format check, unit tests
npm run test:live       # the example app against real boxd machines

test:live runs the example app on an anonymous local Convex backend, with no Convex account and nothing uploaded, against real boxd machines. It needs BOXD_API_KEY in the environment or in .env.e2e.local, and destroys every machine it creates.

demo/ is the public demo: a small React page (demo/src) that boots a machine, runs commands and forks it, all through the component, with its own Convex backend in demo/convex. That backend adds the parts a public page needs on top of the component: anonymous sign-in, an optional password (DEMO_PASSWORD), per-visitor machine caps, rate limits, and a cron that destroys each machine after ten minutes. Demo machines are isolated, so visitor commands can't reach boxd or other machines. Run it with npx convex dev and npm run dev:demo, or build it with npm run build:demo.

example/convex is a reference app that wraps the whole API with no limits. It backs the unit and live tests and is never deployed alongside the demo, since its functions are open to any signed-in user.

License

MIT
