Convex Analytics

A first-party, real-time product analytics component for Convex. Track pageviews, custom events, and user identity directly into your own database—no third-party services required.

• Real-time Ingestion: High-speed HTTP endpoint for event landing.
• Drop-in Dashboard: A complete React component with timeseries charts and metrics.
• First-party Data: You own the data; it stays in your Convex deployment.
• Browser SDK: Tiny, dependency-free client with auto-batching.

Quick Start

Before you start: one write key, two places

Generate one write key for your site.

You will use that same raw key in two places:

• server-side when creating the site
• browser-side when sending ingest requests

Suggested env vars:

• Convex env: ANALYTICS_WRITE_KEY
• frontend env: NEXT_PUBLIC_ANALYTICS_WRITE_KEY or VITE_ANALYTICS_WRITE_KEY

If those two values do not match, events will not be ingested.

1. Install the Convex component

Copy codenpm install @abdssamie/convex-analytics

Copy codeimport { defineApp } from "convex/server";
import convexAnalytics from "@abdssamie/convex-analytics/convex.config.js";

const app = defineApp();
app.use(convexAnalytics, { httpPrefix: "/analytics-component/" });

export default app;

2. Register the ingest route

Copy code// convex/http.ts
import { httpRouter } from "convex/server";
import { components } from "./_generated/api";
import { registerRoutes } from "@abdssamie/convex-analytics";

const http = httpRouter();

registerRoutes(http, components.convexAnalytics);

export default http;

If components.convexAnalytics is missing, start your Convex dev server first so generated component bindings exist:

Copy codenpx convex dev

3. Create the default site once

Create a tiny bootstrap mutation:

Copy code// convex/analytics.ts
import { components } from "./_generated/api";
import { provisionSite } from "@abdssamie/convex-analytics";

export const provisionDefaultSite = provisionSite(components.convexAnalytics, {
  auth: async () => {},
  site: {
    slug: "default",
    name: "Default site",
    writeKey: process.env.ANALYTICS_WRITE_KEY!,
    allowedOrigins: [], // Don't forget allowed origins here to protect your service if key gets leaked
  },
});

Then run it once:

Copy codenpx convex run analytics:provisionDefaultSite

provisionDefaultSite is idempotent. If default already exists, nothing breaks. It also fails fast if your analytics write key env var is missing or empty.

4. Send events from the browser

Copy codeimport { createAnalytics } from "@abdssamie/convex-analytics";

const analytics = createAnalytics({
  endpoint: "https://your-deployment.convex.site/analytics/ingest",
  writeKey: process.env.NEXT_PUBLIC_ANALYTICS_WRITE_KEY!,
  autoPageviews: false,
});

analytics.page();
analytics.track("signup_clicked", { plan: "pro" });
analytics.identify("user_123", { tier: "pro" });

That is enough to start sending analytics.

If your app is not bundling npm modules, you can load the tracker with a plain script tag instead of importing createAnalytics(...) directly.

Auto-init with one script tag:

Copy code<script
  defer
  src="https://unpkg.com/@abdssamie/convex-analytics@latest/dist/embed/convex-analytics.js"
  data-endpoint="https://your-deployment.convex.site/analytics/ingest"
  data-write-key="write_..."
  data-auto-pageviews="true"
></script>

Or initialize it manually:

Copy code<script src="https://unpkg.com/@abdssamie/convex-analytics@latest/dist/embed/convex-analytics.js"></script>
<script>
  window.ConvexAnalytics.init({
    endpoint: "https://your-deployment.convex.site/analytics/ingest",
    writeKey: "write_...",
    autoPageviews: false,
  });

  window.ConvexAnalytics.page();
</script>

Available browser globals:

• window.ConvexAnalytics.init(...)
• window.ConvexAnalytics.page(...)
• window.ConvexAnalytics.track(...)
• window.ConvexAnalytics.identify(...)
• window.ConvexAnalytics.flush()

5. Render the dashboard

After the component and default site are set up, expose the read API from your Convex backend and protect it with auth.

Backend: expose dashboard queries

Copy code// convex/analytics.ts
import { components } from "./_generated/api";
import {
  exposeAdminApi,
  exposeAnalyticsApi,
} from "@abdssamie/convex-analytics";

const auth = async (ctx: { auth: { getUserIdentity: () => Promise<unknown> } }) => {
  const identity = await ctx.auth.getUserIdentity();
  if (!identity) {
    throw new Error("Unauthorized");
  }
};

export const { getSiteBySlug } = exposeAdminApi(components.convexAnalytics, {
  auth: async (ctx) => auth(ctx),
});

export const {
  getDashboardSummary,
  getOverview,
  getTimeseries,
  getTopPages,
  getTopReferrers,
  getTopSources,
  getTopMediums,
  getTopCampaigns,
  getTopEvents,
  getTopDevices,
  getTopBrowsers,
  getTopOs,
  getTopCountries,
  listRawEvents,
  listPageviews,
  listSessions,
  listVisitors,
} = exposeAnalyticsApi(components.convexAnalytics, {
  auth: async (ctx, operation) => {
    await auth(ctx);
    // Add your own site ownership check here for operation.siteId.
  },
});

Frontend: render the dashboard

Copy codeimport { AnalyticsDashboard } from "@abdssamie/convex-analytics/react";
import { useQuery } from "convex/react";
import { api } from "../convex/_generated/api";

export function DashboardPage() {
  const site = useQuery(api.analytics.getSiteBySlug, { slug: "default" });

  if (site === undefined) {
    return <div>Loading...</div>;
  }

  if (site === null) {
    return <div>Default analytics site not found.</div>;
  }

  return (
    <AnalyticsDashboard
      siteId={site._id}
      api={{
        getDashboardSummary: api.analytics.getDashboardSummary,
        getOverview: api.analytics.getOverview,
        getTimeseries: api.analytics.getTimeseries,
        getTopPages: api.analytics.getTopPages,
        getTopReferrers: api.analytics.getTopReferrers,
        getTopSources: api.analytics.getTopSources,
        getTopMediums: api.analytics.getTopMediums,
        getTopCampaigns: api.analytics.getTopCampaigns,
        getTopEvents: api.analytics.getTopEvents,
        getTopDevices: api.analytics.getTopDevices,
        getTopBrowsers: api.analytics.getTopBrowsers,
        getTopOs: api.analytics.getTopOs,
        getTopCountries: api.analytics.getTopCountries,
        listRawEvents: api.analytics.listRawEvents,
        listPageviews: api.analytics.listPageviews,
        listSessions: api.analytics.listSessions,
        listVisitors: api.analytics.listVisitors,
      }}
    />
  );
}

The dashboard itself does not handle authentication. Auth belongs in your backend wrappers, and the React component reads only from those authenticated queries.

Component stores only writeKeyHash, not the raw write key.

The browser write key is an ingest credential, not an admin secret. Treat it like a publishable key: make it long and random, restrict allowedOrigins, and rotate it if leaked.

What It Tracks

• Pageviews
• Custom product events
• Anonymous visitors
• Sessions
• identify(userId, traits) links
• Referrers and UTM campaign fields
• Top pages, events, referrers, and campaigns
• Overview and timeseries reports

Architecture

The component owns its own Convex tables:

• sites: one tracked site/app per write key
• visitors: durable anonymous visitor records
• sessions: session windows and coarse device/browser/country summary
• events: append-only raw events with lightweight aggregation marker
• rollups: hourly/daily report counters

Copy codeflowchart LR
    Browser["Browser SDK / HTTP client"] --> Http["HTTP ingest route"]
    Http --> Ingest["ingestBatch\nappend-only raw event insert"]
    Ingest --> Events[("events")]
    Ingest --> Worker["reducePendingSiteEvents"]
    Worker --> Visitors[("visitors")]
    Worker --> Sessions[("sessions")]
    Worker --> Rollups[("rollups\nhourly + daily")]
    Rollups --> Dashboard["Dashboard queries\ngetOverview/getTimeseries/top lists"]
    Events --> Dashboard
    Sessions --> Dashboard

Why sites exists: one Convex deployment can track multiple sites or apps. For the common one-site case, create one site named default and ignore the multi-site parts until needed.

Browser traffic should use HTTP ingest route. Do not send every browser event through public Convex mutations. SDK batches events and HTTP route hashes write key before calling component.

Ingest and reporting are split on purpose. ingestBatch writes raw events quickly, leaves aggregatedAt: null, and schedules background aggregation. The worker materializes visitors, sessions, and rollups, then stamps aggregatedAt.

Dashboard queries are range-aware:

• overview and top-dimension queries use exact edge handling
• first/last timeseries bucket is clipped to requested range
• raw events can lag by worker time, usually a few seconds

Troubleshooting

Browser shows a CORS error on /analytics/ingest

Example:

Copy codeAccess to fetch at 'https://your-deployment.convex.site/analytics/ingest'
from origin 'http://localhost:3001' has been blocked by CORS policy:
No 'Access-Control-Allow-Origin' header is present on the requested resource.

Check these first:

• the browser is using the same write key you used in provisionDefaultSite
• the site was created successfully
• the current origin is allowed for that site

Why this looks like CORS:

• the ingest route checks the write key and site before returning CORS headers
• if that check fails, the browser often reports a generic CORS error

Useful fixes:

Copy codenpx convex run analytics:provisionDefaultSite

• verify your frontend env var matches ANALYTICS_WRITE_KEY
• verify allowedOrigins includes your local or production domain

components.convexAnalytics is missing

Run your Convex dev server first so generated component bindings exist:

Copy codenpx convex dev

Dashboard says the default site is not found

You registered the component and queries, but the site record does not exist yet. Run:

Copy codenpx convex run analytics:provisionDefaultSite

Dashboard API

When you want to read analytics in your app, expose only the read functions:

Copy code// convex/analytics.ts
import { components } from "./_generated/api";
import { exposeAnalyticsApi } from "@abdssamie/convex-analytics";

export const {
  getDashboardSummary,
  getOverview,
  getTimeseries,
  getEventPropertyBreakdown,
  getTopPages,
  getTopReferrers,
  getTopSources,
  getTopMediums,
  getTopCampaigns,
  getTopEvents,
  getTopDevices,
  getTopBrowsers,
  getTopOs,
  getTopCountries,
  listRawEvents,
  listPageviews,
  listSessions,
  listVisitors,
} = exposeAnalyticsApi(components.convexAnalytics, {
  auth: async (ctx, operation) => {
    const identity = await ctx.auth.getUserIdentity();
    if (!identity) {
      throw new Error("Unauthorized");
    }
    // Add your own site ownership check here for operation.siteId.
  },
});

Dashboard surface:

• getDashboardSummary(siteId, from, to, interval)
• getOverview(siteId, from, to)
• getTimeseries(siteId, from, to, interval)
• getEventPropertyBreakdown(siteId, eventName, propertyKey, from, to, limit?)
• getTopPages(siteId, from, to, limit?)
• getTopReferrers(siteId, from, to, limit?)
• getTopSources(siteId, from, to, limit?)
• getTopMediums(siteId, from, to, limit?)
• getTopCampaigns(siteId, from, to, limit?)
• getTopEvents(siteId, from, to, limit?)
• getTopDevices(siteId, from, to, limit?)
• getTopBrowsers(siteId, from, to, limit?)
• getTopOs(siteId, from, to, limit?)
• getTopCountries(siteId, from, to, limit?)
• listRawEvents(siteId, from?, to?, paginationOpts)
• listPageviews(siteId, from?, to?, paginationOpts)
• listSessions(siteId, from?, to?, paginationOpts)
• listVisitors(siteId, from?, to?, paginationOpts)

Advanced: Site Admin API

You do not need this for the initial install.

Use exposeAdminApi(...) only if your app needs site management:

Copy codeimport { components } from "./_generated/api";
import { exposeAdminApi } from "@abdssamie/convex-analytics";

export const {
  createSite,
  updateSite,
  rotateWriteKey,
  cleanupSite,
} = exposeAdminApi(components.convexAnalytics, {
  auth: async (ctx, operation) => {
    // admin auth / site ownership check here
  },
});

Admin surface:

• createSite, updateSite, rotateWriteKey
• cleanupSite(siteId? | slug?, now?, limit?, runUntilComplete?)

Recommended dashboard shape:

1. getOverview for KPI cards
2. getTimeseries for chart
3. top-dimension queries for tables
4. getEventPropertyBreakdown for lean product-event analysis
5. listRawEvents / listPageviews / listSessions / listVisitors for drill-down/debug

Example product analytics query:

Copy codeawait ctx.runQuery(api.analytics.getEventPropertyBreakdown, {
  siteId,
  eventName: "plan_selected",
  propertyKey: "plan",
  from,
  to,
  limit: 10,
});

Recommended event naming:

• track("plan_selected", { plan: "pro" })
• track("checkout_started", { step: "shipping" })
• identify(userId, { plan: "pro" })

Drill-down queries return Convex pagination objects:

• page
• isDone
• continueCursor

Raw events are append-only source of truth. Rollups are serving layer.

Retention

Retention is configured per site. Defaults are cost-conscious:

• raw events: 90 days
• hourly rollups: 90 days
• daily rollups: kept indefinitely

retentionDays is shared default for raw events and hourly rollups. Override specific fields when needed:

Copy coderegisterRoutes(http, components.convexAnalytics, {
  path: "/analytics/ingest",
  countryLookup: "headers-only",
});

Advanced: Cleanup and Retention

Cleanup is explicit so you control request volume and billing. For most apps, add one cleanup action and one cron and stop thinking about it.

If you want custom schedules, this is the manual shape:

Copy code// convex/cleanup.ts
import { components } from "./_generated/api";
import { internalAction } from "./_generated/server";
import { v } from "convex/values";

export const site = internalAction({
  args: {
    slug: v.string(),
    limit: v.optional(v.number()),
  },
  handler: async (ctx, args) => {
    return await ctx.runAction(components.convexAnalytics.maintenance.cleanupSite, {
      slug: args.slug,
      limit: args.limit,
    });
  },
});

Then schedule them:

Copy code// convex/crons.ts
import { cronJobs } from "convex/server";
import { internal } from "./_generated/api";

const crons = cronJobs();

crons.interval(
  "analytics cleanup",
  { hours: 6 },
  internal.cleanup.site,
  { slug: "default", limit: 100 },
);

export default crons;

These are admin functions. Do not call them from browser clients.

Use runUntilComplete: true only for one-off backfills or after downtime. For normal production cron, keep it unset and let each run delete a bounded batch.

Browser SDK

Use the browser helper in your frontend:

Copy codeimport { createAnalytics } from "@abdssamie/convex-analytics";

const analytics = createAnalytics({
  endpoint: "https://your-deployment.convex.site/analytics/ingest",
  writeKey: "write_...",
  autoPageviews: false,
  flushIntervalMs: 5000,
  maxBatchSize: 10,
});

analytics.page();
analytics.track("signup_clicked", { plan: "pro" });
analytics.identify("user_123", { tier: "pro" });
await analytics.flush();

The SDK stores:

• visitorId in localStorage
• sessionId in sessionStorage
• queued events in memory only

It flushes on interval, batch size, and pagehide.

autoPageviews: true works for traditional full-page loads. For SPAs, call analytics.page() on route changes yourself:

Copy codeuseEffect(() => {
  analytics.page();
}, [analytics, pathname]);

Cost Controls

The default ingest path is built to avoid unnecessary Convex usage:

• Browser events are batched.
• Raw events are slim.
• Write keys are hashed before reaching component storage.
• Ingest does not patch report counters inline.
• Reports use hourly/daily rollups for common analytics queries.
• Cleanup uses indexed, bounded batches and keeps daily rollups by default.
• Event properties can be allowlisted or denied per site.
• Raw IP addresses are not persisted by this component.

Note

While this component has been optimized to reduce convex usage cost, if you have many users or except to do so, then consider another service as convex-analytics hasn't been tested for large scale usage, but most developers don't have to bother about this.

Publishing

Release scripts:

• npm run alpha
• npm run release
• npm run verify:release

Both go through preversion, which runs:

• npm ci
• npm run build:clean
• npm run test
• npm run lint
• npm run typecheck

npm run verify:release adds npm pack on top, matching CI.

The package version script is non-interactive now. It just formats CHANGELOG.md and stages it if needed.

GitHub Actions automation:

• CI runs on every push to main, pull request, and manual dispatch.
• Publish runs on v* tags and manual dispatch.
• Publish requires an NPM_TOKEN repository secret.
• Tag-based publish verifies that vX.Y.Z matches package.json version X.Y.Z.

Development

Copy codenpm install
npm run build:codegen
npm test
npm run typecheck

Run the example app:

Copy codenpm run dev
npm run dev:frontend

The example frontend is a small product app that sends analytics events. It is not a dashboard. Use the Convex dashboard to inspect component tables, functions, and stored events.
