Action Cache

Documentation from convex/action-cache, recorded October 23, 2026. APIs and setup may differ in the Bijection adaptation.

Sometimes your app needs to fetch information from a third-party API that is slow or costs money. Caching can help! This is a Convex component that can cache the results of expensive functions and set an optional TTL. Expired entries are cleaned up via a cron job once a day. The cache key is the ActionCache's name (defaults to function name) and the arguments to the action that generates the cache values.

Copy codeimport { action } from "./_generated/server";
import { components } from "./_generated/api";
import { ActionCache } from "@convex-dev/action-cache";

const cache = new ActionCache(components.actionCache, {
  action: internal.example.myExpensiveAction,
});

export const myFunction = action({
  // NOTE: If we're returning the result, we need explicitly type the return value.
  // Refer to https://docs.convex.dev/functions/actions#dealing-with-circular-type-inference for more info.
  handler: async (ctx, args): Promise<{ text: string }> => {
    // Call it with the parameters to `myExpensiveAction`
    const result = await cache.fetch(ctx, { foo: "bar" });

    // Do something with the result or just return it
    return result;
  },
});

export const myExpensiveAction = internalAction({
  args: { foo: v.string() },
  handler: async (ctx, args): Promise<{ text: string }> {
    const data = await generateLLMResponse(ctx, args);
    return data;
  }
})

To invalidate the cache, you can set a new name explicitly and/or clear cached values by name.

Pre-requisite: Convex

You'll need an existing Convex project to use the component. Convex is a hosted backend platform, including a database, serverless functions, and a ton more you can learn about here.

Run npm create convex or follow any of the quickstarts to set one up.

Installation

Install the component package:

Copy codenpm install @convex-dev/action-cache

Create a convex.config.ts file in your app's convex/ folder and install the component by calling use:

Copy code// convex/convex.config.ts
import { defineApp } from "convex/server";
import cache from "@convex-dev/action-cache/convex.config.js";

const app = defineApp();
app.use(cache);

export default app;

Finally, create a new ActionCache with optional name and expiration within your Convex project, and point it to the installed component.

• The name field can be used for identifying the function or version being used to create the values in the cache and can also be used for grouping entries to remove.
• The ttl (Time-To-Live) field determines how long the cache entries are valid, in milliseconds.
  • If no ttl is provided, the cache entries are kept indefinitely.
  • If an ttl is provided, expired cache entries are deleted when they are retrieved and in a daily cron job.

Copy codeimport { ActionCache } from "@convex-dev/action-cache";
import { components } from "./_generated/api";

const cache = new ActionCache(components.actionCache, {
  action: internal.example.myExpensiveAction,
  name: "myExpensiveActionV1",
  ttl: 1000 * 60 * 60 * 24 * 7, // 7 days
});

Example

Suppose you're building an app that uses vector search. Calculating embeddings is often expensive - in our case, we are using OpenAI's API which adds latency to every search and costs money to use. We can reduce the number of API calls by caching the results!

Start by defining the Convex action that calls the API to create embeddings. Feel free to substitute your favorite embeddings API. You may need to adjust the vector dimensions in the schema in example/schema.ts accordingly.

Set your API key environment variable

Copy codenpx convex env set OPENAI_API_KEY <your-api-key>

Copy codeexport const embed = internalAction({
  args: { text: v.string() },
  handler: async (_ctx, { text }) => {
    const apiKey = process.env.OPENAI_API_KEY;
    if (!apiKey) {
      throw new Error("OPENAI_API_KEY environment variable not set!");
    }
    const req = { input: text, model: "text-embedding-ada-002" };
    const resp = await fetch("https://api.openai.com/v1/embeddings", {
      method: "POST",
      headers: {
        "Content-Type": "application/json",
        Authorization: `Bearer ${apiKey}`,
      },
      body: JSON.stringify(req),
    });
    if (!resp.ok) {
      const msg = await resp.text();
      throw new Error(`OpenAI API error: ${msg}`);
    }
    const json = await resp.json();
    const vector = json["data"][0]["embedding"];
    console.log(`Computed embedding of "${text}": ${vector.length} dimensions`);
    return vector as number[];
  },
});

Create the embeddings cache:

Copy codeconst embeddingsCache = new ActionCache(components.actionCache, {
  action: internal.example.embed,
  name: "embed-v1",
});

Use the cache when you run a vector search:

Copy codeexport const vectorSearch = action({
  args: { query: v.string(), cuisines: v.array(v.string()) },
  handler: async (ctx, args) => {
    const embedding = await embeddingsCache.fetch(ctx, {
      text: args.query,
    });
    const results = await ctx.vectorSearch("foods", "by_embedding", {
      vector: embedding,
      limit: 16,
      filter: (q) =>
        q.or(...args.cuisines.map((cuisine) => q.eq("cuisine", cuisine))),
    });
    const rows: SearchResult[] = await ctx.runQuery(
      internal.example.fetchResults,
      { results },
    );
    return rows;
  },
});

Defining multiple caches

You can use the same component for multiple actions, or multiple versions of the same action. You can specify a custom name argument to denote which cache you want to use, or change the name to start fresh, like embed-v2.

If the return value changes, it is important to change the name so you don't get unexpected values.

Updating the cache before it expires

It's convenient to lazily run the action when there is a cache miss. However, this means that some requests will be slow, and many competeing requests may race to all run the action and populate the cache.

You can avoid this by calling fetch with the force option. This will force the action to run and update the cache, even if there is a cache hit. In the meantime, other requests will get a cache hit.

If you call this from a cron job, the cache will always have an entry (unless the action fails).

Clearing values

To clear old values, you can:

1. Remove one entry by arguments.

   Copy codeawait embeddingsCache.remove(ctx, { text: "target text" });


2. Remove all entries for the current name (defaults to function name). This is useful if you updated the implementation and want to clear

   Copy codeawait embeddingsCache.removeAllForName(ctx);


3. Remove all entries in the component, including all names.

   Copy codeawait embeddingsCache.removeAll(ctx);


See more example usage in example.ts.
